Performance feature:
◆Touch screen can be rotated as you like
◆Automatic measurement of left and right eyes
◆Automatic paper cutting
◆Bluetooth communication
| Specifications | ||
Measurement mode | K/R mode: | Diopter and corneal curvature measurements |
| REF mode: | Diopter measurement | |
| KRT mode: | Corneal curvature measurement | |
Diopter measurement | Vertical distance (VD) | 0mm、12.0mm、13.75mm、15.00mm |
| Spherical degree measurement range | -25.00D～+25.00 | |
| Column mirror measurement range | -10D～+10D | |
| Axis measurement range | 0°～180° | |
| Interpupillary distance measurement range | 10mm～85mm | |
| Minimum measurement pupil diameter | ф2.0mm | |
Corneal measurement | Radius of curvature measurement range | 5mm～10mm |
| Direction of corneal Astigmatic axis | 0°～180° | |
| Corneal diameter | 2.0mm～12mm | |
Product specifications | Display | 9” Touch LCD monitor |
| Printer | Import thermal printer | |
| Power saving mode | 1/5/10/40 minutes no operation | |
| Power supply | AC220V;50Hz 75VA | |
| Size/Weight | 300(W)*450(D)*500-530(H)mm/20kg | |
| Chart | Automatic fogging method | |
